TECHNICAL SPECIFICATIONS

APPLICATIONS

MEASUREMENT CAPABILITIES

Contact angle range: 0 – 180°

Precision: +/-0.1°

Surface tension range: 0.01 – 2000 mN/m

Resolution: 0.01 mN/m

Dynamic measurement: 170 – 4276 im./s

• Contact angle measurement

• Liquid surface tension measurement

• Surface energy measurement

• Dynamic contact angle measurement

• Wetting hysteresis measurement

DROPLET FORMATION

Electronic dosing

Droplet size: 1 – 10 µl

Liquids: DI water and others possible

SAMPLE STAGE

Large stage 100mm x 100mm

Thickness range: 0-70 mm

Manual XYZ-table

OPTICS

USB Camera 2048px x 1088px

Optical x6.5 Zoom

Backside LED illumination

ACCESS

SELF-SERVICE MACHINE AFTER TRAINING (OPEN TO INTERNS)
